Feature:
- H.265, H.264, MJPEG tri-encoder
- Sony Starvis™ 1/2” Starlight Super low lux and full color
- Internal ICR , and long distance IR LED，Automatic day and night switch
- Cyber security :1x, IP filter, HTTPS, RTC
- 307 or 316 level stainless casing. Anti-salt casing for seashore application
|
Camera |
|
|
Image Device |
Sony 1/2”CMOS sensor , 2MP Starlight super low lux sensor |
|
Effective pixels |
1920x1080 |
|
Lens focal length |
Support C, CS mount. DC and P-iris lens ( * contact your sales to order lens with camera) |
|
Min. Illumination |
Color: 0.01 lux @F1.2 (AGC on) B/W: 0.005 lux @F1.2 (AGC on) |
|
Day &Night |
Mechanical ICR, Support 3 modes: Fully automatic switching, manual switching, external DI switching |
|
Shutter |
1/5-1/10,000s |
|
WDR |
Extreme WDR. Auto/Manual |
|
Video |
|
|
Video Encoder |
H.265, H.264 and MJPEG simultaneously |
|
Video Profiles |
Four-encoder simultaneously 1920x1080, 1280x720, 640x480, 320x240 |
|
Frame Rate |
2MP 60fps mode |
|
Exposure Control |
Auto / Auto Indoor / Manual Exposure BLC Electronic Shutter Auto/Auto Indoor/Manual |
|
Image Setting |
AGC AE, AWB, Manual WB Control Automatic and manual shutter control 2D, 3D Noise reduction Color, brightness, sharpness, contrast, Hue Image Mirror/Flip, 90° Rotation |
|
On Screen Display |
Text, time and date overlay |
|
Network |
|
|
Application Programming Interface |
ONVIF Profile G, S, T and udated ONVIF test tool |
|
Supported Protocols |
IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, DIPS, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, Samba, ICMP, SNMP, QoS, 802.1x |
|
Network Package |
Support Unicast and Multicast |
|
Cyber Security |
Password protection, IP address filtering, HTTPS encrypted data transmission, user access log, 802.1x, RTC (realtime clock) |
|
Users |
10 simultaneous unicast users |
|
Ethernet |
10M/100M auto detection |
|
Alarm |
|
|
Alarm Triggers |
AI inside: Person detection, Car detection, Cross line, Restricted area (virtual fence) Camera IVA: Video motion detection: Cell motion, polygon area Camera Tampering Audio Detection (*MIC connected) Digital input Network Disconnect mSD card fail to read |
|
Alarm Events |
( Apply to camera AI trigger and IVA trigger ) File upload via FTP server (picture) File upload via email (picture) File upload via Samba to NAS (picture) Send notification via HTTP, and TCP External output activation (DO) Audio alerting output Save to local mSD card (picture, and edge recording ) ICR On/Off |
|
General |
|
|
Power Supply |
12V DC in |
|
Working Temperature |
-20°C to 65°C |
|
Operating Humidity |
20% ~ 80% (non-condensing) |
|
Casing Degree |
307 stainless ( or 316 stainless ) IP67 weather proof IK10 vandal proof |
|
Certification |
CEL EN55024, EN55032, EN50121, EN62328 FCC IEN60068 ( temperature test) RoHS declaration |
|
Viewing System |
|
|
OS |
Windows® 7, 10 |
|
Browser |
IE™, Chrome |
|
Management Utility |
|
|
Batch management |
IP Wizard III ™: Batch upgrade firmware, backup parameter, and restore parameter |
